Fortu Tech specializes in manufacturing C-129Y Niobium Alloy (Nb-10W-10Hf-0.1Y) products.
| C-129Y Niobium Alloy Nb-10W-10Hf-0.1Y | ||
| C-129Y Foil | C-129Y Wire | C-129Y Sheet |
| C-129Y Rod | C-129Y Targets | C-129Y Tube |
| C-129Y Pellet | C-129Y Fasteners | C-129Y Ingot |
Nb C-129Y alloys is a kind of niobium-tungsten-hafnium refractory alloy. Nb-10W-10Hf-0.1Y is its main chemical composition. The density is 9.5g/cm3.
It not only has high temperature performance but also heat resistance and oxidation resistance as well. It is commonly used in manufacturing missiles and spacecraft.
Nb-10W-10Hf-0.1Y alloys is sensitive to hydrogen, oxygen, nitrogen and other interstitial elements. And, its DBTT is relatively high.
In the welding condition, the DBTT is generally above room temperature. During the state of producing and using, the content of oxygen and nitrogen must be controlled below 80x10-6.
| Chemical Requirements C-129Y Niobium Alloy Nb-10W-10Hf-0.1Y | |||||||
| Element | W | Hf | Y | C | N | O | H |
| Content Maximum % | 9.0-11.0 | 9.0-11.0 | 0.2 | 0.1 | 0.015 | 0.03 | 0.002 |
If you have inquiry or want to discuss your design with us, please write email to us.
We will reply your email within 24 hours.
| C-129Y Niobium Alloy Nb-10W-10Hf-0.1Y | |||
| Mechanical Properties in 21℃ | Tensile Strength | Yield Strength | Elongation |
| 632.8 Mpa | 534.3 Mpa | 25% | |
| Physical Properties | Coefficient of Line-expansion/ 10-6K-1 | Recrystallization Temperature | Anneal Temperature |
| 4.73 (1371˚C) | 1038˚C - 1093˚C | 982˚C | |
| Mechanical Property C-129Y Niobium Alloy Nb-10W-10Hf-0.1Y | ||
| σb | δ | Temperature |
| 450~600 MPa | 20%~30% | Room Temperature |
Nb C129Y alloys have a variety of high temperature applications.
Nb-10W-10Hf-0.1Y is widely used in aerospace industry and high temperature industry. It is used for manufacturing riveted and fastened structures such as bolts, nuts.
