Fortu Tech specializes in manufacturing Ti Grade 23 products.
| Ti-6Al-4V-ELI-alloy Regular Product | ||
| Ti Grade 23 Foil | Ti Grade 23 Wire | Ti Grade 23 Sheet |
| Ti Grade 23 Rod | Ti Grade 23 Targets | Ti Grade 23 Tube |
| Ti Grade 23 Pellet | Ti Grade 23 Fasteners | Ti Grade 23 Ingot |
Ti Grade 23 Titanium alloy is a strong and durable alloy. ELI means Extra Low interstial. Ti-6Al-4V-ELI-alloy has excellent resistance to acid and gas corrosion. Ti Grade 23 has excellent fracture toughness and faTigue strength.Ti-6Al-4V-ELI plate, Ti-6Al-4V-ELI rod, Ti-6Al-4V-ELI foil, Ti-6Al-4V-ELI wire are the most commonly used alloys in the alpha-plus-beta class.
Ti Grade 23 differs from Ti Grade 5 in its purity: Grade 23 Titanium alloys have a higher purity due to reduced oxygen content to 0.13%(Max).
Reduced interstitial elements oxygen and iron improve plasticity and fracture toughness.
| Chemical Requirements Ti Grade 23 | |||||||
| Element % | Ni | C | H | Fe | O | Al | V |
| Titanium Grade 23 | 0.03 | 0.08 | 0.0125 | 0.25 | 0.13 | 5.5-6.5 | 3.5-4.5 |
If you have inquiry or want to discuss your design with us, please write email to us.
We will reply your email within 24 hours.
| Mechanical Properties Ti-6Al-4V-ELI-alloy | |||
| ASTM Standard | Ultimate Tensile Strength | Yield Strength | Elongation |
| ASTM B265 Grade 23 | 828 MPa | 759 MPa~310 MPa | 10% |
| ASTM B348 Grade 23 | 828 MPa | 759 MPa | 10% |
| ASTM B381 Grade 23 | 828 MPa | 759 MPa | 10% |
| ASTM B861 Grade 23 | 828 MPa | 759 MPa | 10% |
| ASTM B862 Grade 23 | 828 MPa | 759 MPa | 10% |
Ti Grade 23 Titanium alloys are ideal for saltwater environments. Ti-6Al-4V-ELI-alloy can be machined at low speeds with moderate coolant flow and high feed rates.
Ti-6Al-4V-ELI plate, Ti-6Al-4V-ELI rod, Ti-6Al-4V-ELI foil, Ti-6Al-4V-ELI wire are often deployed in the manufacture of aerospace and Marine vessels.
High-quality watches also use Ti-6Al-4V-ELI-alloy to create balance wheels.
Ti-6Al-4V-ELI-alloy is the best choice of implant material. Ti Grade 23 rod is also used to make dental implants.
