Fortu Tech is an ISO Certified Corporation located in China and specializes in manufacturing Pure Vanadium Foil. We have more than 20 years of production experience. Our products are Conflict Free material.
| Common specifications | ||||||||
| Thickness inch | 0.01 | 0.02 | 0.03 | 0.04 | 0.05 | 0.08 | 0.1 | 0.125 |
| Thickness mm | 0.254 | 0.508 | 0.762 | 1.016 | 1.27 | 2.032 | 2.54 | 3.175 |
The CAS Number of vanadium strip is 7440-62-2.
Vanadium foil is a shiny silver-gray metal with a relative density of 6.11g/cm3.
The melting point of V strips is 1917 ° C and boiling point of Vanadium strip is 3421 ° C. Resistivity of V foil is 24.8x10-8Ω·m. Vanadium foil belongs to high melting point rare metals.
The Physical property of pure vanadium is hard, non-magnetic, and malleable, but if it contains a small amount of impurities, especially nitrogen, oxygen, hydrogen, etc., its plasticity can be significantly reduced. Pure vanadium is a typical plastic metal, ductile and can be cold worked into vanadium foils. Vanadium's properties are similar to tantalum and niobium, which provides the basis for the three of them to form a subgroup in the periodic table.
| Mechanical Properties of Vanadium | ||
| Ultimate Tensile Strength | Yield Strength | Elongation |
| 60 000 min, psi | 45 000 min, psi | 20% |
| 420 min, Mpa | 320 min, Mpa | 20% |
If you have inquiry or want to discuss your design with us, please write email to us.
We will reply your email within 24 hours.
| Cas No. of Vanadium Foil | 7440-62-2 |
| EINECS No.of Vanadium Foil | 231-171-1 |
| Density of Vanadium | 6.11 g/cm3 |
| Melting Point of Vanadium | 1917 ℃ |
| Boiling Point of Vanadium | 3421 ℃ |
| Water solubility of Vanadium | insoluble |
| UN Dangerous Goods number of Vanadium | 3289 |
| Atomic weight of Vanadium | 50.9415 |
Due to its high purity and corrosion resistance, vanadium foil is widely used in corrosion resistant industry and can resist various corrosive environments. Vanadium foil also plays a great role in alloy steel and catalyst making. Vanadium strips also have important applications in the coating industry, which can improve the performance and durability of coatings. Vanadium battery (all vanadium REDOX flow battery) is an efficient energy storage device, which has the characteristics of high power, large capacity, high efficiency and long life. Vanadium alloy medical devices have high strength and biocompatibility, and can be used in procedures such as repairing fractures and joint replacements.
In addition to Vanadium Foil and Strip, we also produce Vanadium Tube & Pipe, Vanadium Sheet & Plate, Vanadium Ingot, Vanadium Pellets, Vanadium Rod, Vanadium Wire, Vanadium Disc, Vanadium Shield, Vanadium Target, Vanadium machined parts,Vanadium Additive.
