Fortu Tech is an ISO Certified Corporation located in China and specializes in manufacturing C103 Niobium-Hafnium Alloy Target. We have more than 20 years of production experience. Our products are Conflict Free material.
| Common specifications | ||||||||
| Thickness inch | 0.15 | 0.2 | 0.25 | 0.3 | 0.35 | 0.4 | 0.45 | 0.5 |
| Thickness mm | 3.81 | 5.08 | 6.35 | 7.62 | 8.89 | 10.16 | 11.43 | 12.7 |
Fortu Tech can customize the Nb10Hf alloys Target according to your demand. Welcome to contact us if you have any questions or requirements.
C103 Niobium-Hafnium Alloy Target of us meets the standard ASTM B654 R04295.
Therefore, Niobium Hafnium C103 alloys Target can be used in some harsh environments. Columbium Nb-C103 alloys machining to Nb-C103 alloys target is feasible.
| ASTM B654 Chemical Requirements Niobium-Hafnium Alloy Target R04295 | |||||||||
| Element % | Hf | Ti | C | O | N | H | Zr | W | Ta |
| Content Maximum % | 9-11 | 0.7-1.3 | 0.015 | 0.025 | 0.01 | 0.0015 | 0.7 | 0.5 | 0.5 |
If you have inquiry or want to discuss your design with us, please write email to us.
We will reply your email within 24 hours.
| Mechanical Properties of Nb C103 alloys Target ASTM B654 | |||
| Ultimate Tensile Strength | Yield Strength | Elongation | |
| Room temperature: | 54 000 min, psi | 38 000 min, psi | 20% |
| Room temperature: | 370 min, MPa | 260 min, MPa | 20% |
| 2000+/- 25°F [1100 +/- 15°C]: | 21 000 min, psi | 16 000 min, psi | 20% |
| 2000+/- 25°F [1100 +/- 15°C]: | 145 min, MPa | 110 min, MPa | 20% |
Size: 0.051 in. [1.3 mm] and greater in thickness
Niobium Hafnium alloys Target is less weight than conventional metals. The heat resistance of Columbium Nb10Hf alloys Target is better than that of niobium alloys. Some machined parts of equipment in the aerospace industry can be processed with Nb10Hf alloys Target. In the Niobium alloy, the low temperature resistance of Niobium C-103 Alloys Target is also very advantageous. The exploration of the universe requires a variety of equipment, Nb10Hf alloys Target has become one of the important materials for equipment of space exploration.
In addition to Niobium C-103 alloys Target, we also produce Niobium C-103 alloys Ingot, Niobium C-103 alloys Sheet & Plate, Niobium C-103 alloys Rod & Bar, Niobium C-103 alloys Wire, Niobium C-103 alloys Disc, Niobium C-103 alloys machined parts, Niobium C103 Alloy Spherical Powder. They meet Standard R04295, ASTM B 652, ASTM B 655, ASTM B 654, AMS 7852, AMS 7857.
